DELL EMC SC9000 ARRAY CONTROLLER
DELL EMC SC9000 ARRAY CONTROLLER Best Price & Specification
Chassis :
Height: 2U/87.3 mm (3.44 inches)
Width: 482.4 mm (18.98 inches) with rack latches; 444 mm (17.08 inches) without rack latches
Depth: 755.8 mm (29.75 inches) with bezel
Weight: 19.73 kg (43.5 lb)
Rack support :
ReadyRails™ II static rails for tool-less mounting in 4-post racks with square or unthreaded
round holes or tooled mounting in 4-post threaded-hole racks
Connectivity :
PCIe Gen 3 slots
7 per controller
4 full-height (cache card consumes one), 3 low-profile
Any slot may be used for either front-end network or back-end expansion capacity connections
Environmental Operating Conditions :
Operating: 41º to 104ºF ( 5º to 40ºC ) Non-operating: -40º to 149ºF ( -40º to 65ºC )
Management :
Management interface
Browser-based (HTML 5)
Unisphere for SC (element manager)
Unisphere Central (multi-array management)
CloudIQ (cloud-based analytics and monitoring)
Power :
Power/wattage: 2 hot-swappable 1100W 80 PLUS® Energy Star Platinum-certified power supplies
Maximum output power: 1100 W
Maximum input power: 1200 W
Maximum input current: 12 A
Maximum inrush current: 25A for 10 ms or less
Nominal input voltage operating range: 100-240 VAC
Nominal input frequency: 50/60 Hz
Maximum thermal output/heat dissipation: 4,760 BTU per
Energy Efficiency :
The Dell EMC SC7020 arrays have earned the ENERGY STAR Data Center Storage designation
Storage :
Block (SAN)*
Expansion enclosures :
Mix and match from the following options:
Dell SC400: 12 x 3.5" drive bays, 12Gb SAS
Dell SC420: 24 x 2.5" drive bays, 12Gb SAS
Dell SC460: 60 x 3.5” drive bays, 12Gb SAS
Dell SC280: 84 x 3.5" drive bays, 6Gb SAS*
Dell SC200: 12 x 3.5” drive bays, 6Gb SAS*
Dell SC220: 24 x 2.5” drive bays, 6Gb SAS*
