FortiGate 300E Firewall
FortiGate 300E Firewall Best Price & Specification
FORTIGATE 300E FORTIGATE 301E
Interfaces and Modules:
- GE RJ45 Interfaces : 16
- GE SFP Slots : 16
- GE RJ45 Management Ports : 2
- USB Ports : 2
- RJ45 Console Port : 1
- Local Storage : 2x 240 GB SSD
- Included Transceivers : 2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix:
- IPS Throughput : 5 Gbps
- NGFW Throughput : 3.5 Gbps
- Threat Protection Throughput : 3 Gbps
System Performance and Capacity:
- IPv4 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 32 / 32 / 20 Gbps
- IPv6 Firewall Throughput(1518 / 512 / 64 byte, UDP) : 32 / 32 / 20 Gbps
- Firewall Latency (64 byte, UDP) : 3 ?s
- Firewall Throughput (Packet per Second) : 30 Mpps
- Concurrent Sessions (TCP) : 4 Million
- New Sessions/Second (TCP) : 300,000
- Firewall Policies : 10,000
- IPsec VPN Throughput (512 byte) : 20 Gbps
- Gateway-to-Gateway IPsec VPN Tunnels : 2,000
- Client-to-Gateway IPsec VPN Tunnels : 50,000
- SSL-VPN Throughput : 2.5 Gbps
- Concurrent SSL-VPN Users(Recommended Maximum, Tunnel Mode):5,000
- SSL Inspection Throughput (IPS, avg. HTTPS) : 3.9 Gbps
- SSL Inspection CPS (IPS, avg. HTTPS) : 2,500
- SSL Inspection Concurrent Session (IPS, avg. HTTPS) : 340,000
- Application Control Throughput (HTTP 64K) : 7 Gbps
- CAPWAP Throughput (1444 byte, UDP) : 5 Gbps
- Virtual Domains (Default / Maximum) : 10 / 10
- Maximum Number of FortiSwitches Supported : 72
- Maximum Number of FortiAPs (Total / Tunnel) : 512 / 256
- Maximum Number of FortiTokens : 5,000
- High Availability Configurations : Active-Active, Active-Passive, Clustering
Dimensions and Power:
- Height x Width x Length (inches) : 1.75 x 17.0 x 15.0
- Height x Width x Length (mm) : 44.45 x 432 x 380
- Weight : 16.1 lbs (7.3 kg) 16.6 lbs (7.6 kg)
- Form Factor (supports EIA / non-EIA standards) : Rack Mount, 1 RU
- Power Consumption (Average / Maximum) : 90 W / 173 W 95 W / 180 W
- Power Input : 100V–240V AC, 50–60Hz
- Current (Maximum) : 6A
- Heat Dissipation : 570 BTU/h 614 BTU/h
- Redundant Power Supplies (Hot Swappable) : optional
Operating Environment and Certifications:
- Operating Temperature : 32–104°F (0–40°C)
- Storage Temperature : -31–158°F (-35–70°C)
- Humidity : 10–90% non-condensing
- Noise Level : 48 dBA
- Operating Altitude Up to : 7,400 ft (2,250 m)
- Compliance : FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
- Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6
