SonicWall TZ600 Firewall

Security Processor: 4x 1.4 GHz

Memory (RAM): 1 GB

1 GbE Copper interfaces : 10

Expansion : Expansion Slot (Rear), 2 USB

Firewall inspection throughput: 1.5 Gbps

Full DPI throughput: 500 Mbps

Application inspection throughput:1.1 Gbps

IPS throughput :  1.1 Gbps

Anti-malware inspection throughput :  500 Mbps

IMIX throughput :  900 Mbps

SSL Inspection and Decryption (DPI SSL) :200 Mbps

VPN throughput : 1.1 Gbps

Connections per second : 12,000

Maximum connections (SPI) : 150,000

Maximum connections (DPI) : 125,000

Single Sign-On (SSO) Users  : 500

VLAN interfaces : 50

SonicPoints supported (Maximum) : 24

Site-to-Site VPN Tunnels : 50

IPSec VPN clients (Maximum) :  2 (25)

SSL VPN licenses (Maximum) : 2 (200)

Virtual assist bundled (Maximum) : 1 (30-day trial)

Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography

Key exchange : Diffie Hellman Groups 1, 2, 5, 14

Route-based VPN : RIP, OSPF

Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP

VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN

Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit

NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE

Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)

Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL

Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists

Enforced Client Anti-Virus and Anti-Spyware : McAfee®

Comprehensive Anti-Spam Service : Supported

Application Intelligence and Control : Yes

Application Visualization : Yes

IP address assignment :  Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay

NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode

Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast

QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)

Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix

Local user database : 150

VoIP : Full H.323v1-5, SIP

Standards  : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3

Certifications : VPNC, IPv6 (Phase 2)

Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL

Common Access Card (CAC) : Supported

High Availability : Active/Standby with stateful synchronization

Form factor : Desktop

Power Supply (W) : 36W external

Maximum power consumption (W) : 13.4 / 17.7

Input power : 100 to 240 VAC, 50-60 Hz, 1 A

Total heat dissipation : 45.9 / 60.5 BTU

Dimensions : 3.5x15x22.5cm

Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs

WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs

Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs

MTBF (Years) : 20 / 12

Environment : 40-105° F, 0-40° C

Humidity : 5-95% non-condensing
